The V4Pro is a highly reliable frame accurate controller. It is not a PC. Its embedded design means it is capable of running every day for years without ever requiring a reboot, software update or maintenance of any kind.
For over two decades, the V16 has been the industry standard for show control in major theme parks all over the world. The V4Pro builds on that legacy of stability, ease of programming, and reliability and adds customer requested features. For smaller venues, the V4Pro is the perfect solution.
The V4Pro features dual Ethernet ports, real-time clock scheduler, incoming message processing, Graphical User Interface (GUI), and much more. The Timeline feature offers a flexible way to program events on the Pro Controllers, which supports hundreds of time-based and event-based sequences and hundreds of timelines. This feature allows users to add markers, drag and drop events, add triggers, and group related events for fast editing. With the flexibility of timeline, users can change event values and times all while the show is running. Timeline can zoom in to a specific point in the show and mix timed and logical events on a single view without overlapping events.
Better yet, combining the V4Pro with our audio and video players, you create the technical backbone of an attraction without using a single computer or hard drive! This means less downtime, and more predictable operating costs.
Combine the V4Pro with our audio/video players and lighting controllers for a solid system that will outlast any other.
CONTROL |
|
---|---|
Front Panel | 8×40 VFD Display Power LED Acknowledge (ACK) LED Error LED Timecode LED Video Sync LED 4 Serial Activity LEDs (Bi-color for TX and RX) 16 Input Status LEDs 16 Output Status LEDs 16 Programmable Pushbuttons |
Rear Panel | USB 2.0 Programming Port Serial Programming Port DB-9M 4 Serial Ports DB-9M MIDI Input 5-pin DIN Female MIDI Output 5-pin DIN Female Discrete Inputs DB-37M Discrete Outputs DB-37F Video Sync Input BNC Dual 10/100 Base-T Ethernet RJ-45 Power locking barrel connector 4 Position DIP Switch: 75 ohm Sync Termination, Sync Type, Reset, Option |
Serial Ports | RS-232C or RS-422, individually software configurable 300 baud – 115.2 Kbaud 7, 8, or 9 Data Bits 1 or 2 Stop Bits All parity types |
Opto Inputs | Individually software configurable for voltages or contact closures Input voltage range 5-24 VDC, 5 mA maximum Hardware protected against misconfiguration Trigger latency < 1 frame |
Relay Outputs | Contact Closures limited internally to 900 mA Self-restoring polymer fuses |
Show Memory | Compact Flash |
Real Time Clock | Internal, battery backed, synchronized by Internet time server |
Ethernet | Dual 100 Base-T Ethernet ports |
PHYSICAL |
|
Size | 19″W x 10.25 “D x 3.5″H (48.25 cm W x 26 cm D x 9 cm H), 2 RU |
Weight | 9.5 lbs. (4.3 Kg) |
Operating Temperature | 0°C (32°F) to 38°C (100°F), 0-90% Relative Humidity |
Operating Environment | 0-90% relative humidity, non-condensing |
AC Adapter | 100-250 VAC, 50-60 Hz, 20W maximum |
Power Supply Compliance | UL, CE, CSA, WEEE, RoHS |
DOCUMENTS |
||
---|---|---|
V4Pro Cut Sheet | Cut Sheet | |
V4Pro User’s Guide | User’s Guide | |
SOFTWARE |
Application | Description | Download |
---|---|---|
WinScript Live 5 (Windows) | Alcorn McBride Show Control IDE for Windows | |
WinScript Live 5 (OS X) | Alcorn McBride Show Control IDE for OS X | |
AMI Terminal | Serial/Ethernet control utility for Windows |
FIRMWARE |
---|
Product | Description | Download |
---|---|---|
V4Pro | Firmware for V4Pro show controller |
REPLACEMENT PARTS |
|
---|---|
CETHN | Spare Peer-to-Peer Ethernet Null Cable |
IOBB | I/O Breakout box includes CP-37 Pin Cable and 37 Pin terminal block |
DIN19 | DIN Rail for mounting IOBB in standard equipment rack |
KDB37M | DB-37 Male Solder-cup Connector Kit with Housing |
KDB37F | DB-37 Female Solder-cup Connector Kit with Housing |
CP37 | 37 Pin Cable, for controller IO ports |
DBWP-10 | Serial Cable, 9 Pin Female to 9 Pin Female, 10 Feet |
DBWP-25 | Serial Cable, 9 Pin Female to 9 Pin Female, 25 Feet |
CNU-2 | Serial Cable, 9 Pin Female to 9 Pin Female, Null Modem, 2 Feet |
CNU-10 | Serial Cable, 9 Pin Female to 9 Pin Female, Null Modem, 10 Feet |
USBSER | USB to RS232 Serial Adapter for Computer |
PS12VU | Spare Universal Power Supply 12V |
